ABB XM06B5 ANALOG INPUT OUTPUT EXTENSION MODULE XM06B5-H11.0 1SBP260103R1001
ABB
XM06B5
1SBP260103R1001
XM06B5-H11.0
4 INPUTS +/- 10V DC
+/-20MA
4-20MA
0.25MA DC (PT1000) 2.5MA DC (PT100)
0.25MA DC (BAL.500-NI1000)
2 OUTPUTS 0-10V DC 2MA
0-20MA DC
4-20MA DC
AWG14CU STR60°C TORQUE 4.5IBS-INCH (0.5NM)
EXTENSION
4 ANALOG INPUTS
2 ANALOG OUTPUTS
MADE IN FRANCE
REF : FKM7966
The ABB XM06B5 is an analog input/output extension module designed to expand the signal handling capability of ABB automation and control systems. Onboard vessels, this module plays a critical role in monitoring and controlling analog signals from sensors and actuators across machinery spaces, HVAC systems, power management, and process control installations. Reliable analog I/O expansion is essential for maintaining precise control over temperature, pressure, flow, and other parameters in demanding marine environments.
Key Features
✓ 4 analog inputs supporting ±10V DC, ±20mA, 4–20mA, and RTD sensor configurations (PT100, PT1000, Ni1000)
✓ 2 analog outputs supporting 0–10V DC and 0/4–20mA DC output ranges
✓ Extension module architecture for scalable integration with ABB control platforms
✓ Robust terminal connections rated for AWG14 conductors with 0.5 Nm torque specification
✓ Manufactured in France to ABB industrial quality standards
Marine Applications
Expansion of automation systems in engine room monitoring and alarm platforms
Analog signal acquisition for temperature, pressure, and flow sensors across auxiliary machinery
Integration into HVAC and ventilation control systems onboard commercial and naval vessels
Power management and generator control system analog I/O extension
Process control and ballast system instrumentation signal handling
Why Marine Engineers Choose
The ABB XM06B5 provides dependable analog signal expansion in a compact, field-proven module that integrates seamlessly with existing ABB automation architectures. Marine engineers trust ABB extension modules for their signal accuracy, robust construction, and proven reliability in shipboard environments where uptime is critical.
Ideal For
Bulk carriers, container vessels, tankers, offshore platforms, cruise ships, naval vessels, ferries, and any marine installation utilising ABB automation and control systems requiring analog I/O expansion.
Technical Support & Compliance
We provide complete support solutions including remote troubleshooting, onboard technical support, testing and commissioning, repair services, retrofit and upgrade assistance, and full integration support for ABB automation modules. To confirm compatibility with your specific installation, please share nameplate photos, part numbers, system drawings, system model and software version, vessel name and IMO number, and project scope. All compatibility and technical specifications are subject to confirmation based on your vessel’s configuration.
