Description
ABB TP 180DA TIMER BLOCK 10-180S (NEW OPEN BOX)
ABB
TP 180DA
TIMER BLOCK
10-180S
LTH= 10A UI= 690V~
UE: 230 400 500 690V~
MADE IN FRANCE
REF.NO: FKM15722
The ABB TP 180DA is a pneumatic timer block with an adjustable delay range of 10 to 180 seconds, designed for front-mounting on ABB contactors and motor starters. Rated for voltages up to 690V AC and 10A, this timer block is widely used in marine electrical systems where precise, repeatable time-delay functions are critical for motor control, sequential operations, and automation circuits aboard vessels.
Key Features
✓ Adjustable on-delay timing range: 10 to 180 seconds for flexible control applications
✓ Rated insulation voltage (UI) of 690V AC, suitable for marine high-voltage distribution systems
✓ Multiple operating voltage options: 230V, 400V, 500V, and 690V AC
✓ Front-mounting design for direct integration with ABB contactor platforms
✓ Manufactured in France to ABB industrial quality standards
Marine Applications
Motor starter time-delay control in engine room auxiliary systems such as pumps, fans, and compressors
Sequential starting of large inductive loads to reduce inrush current on ship generators
Automated HVAC system control with timed relay logic on passenger and cargo vessels
Ballast pump and fire pump motor control circuits requiring adjustable delay-on functions
Integration into main switchboard and emergency switchboard contactor assemblies
Why Marine Engineers Choose
The ABB TP 180DA timer block delivers reliable, adjustable time-delay functionality critical for protecting marine electrical systems during motor starting sequences and automated process control. Its robust construction and wide voltage compatibility make it a trusted component in demanding shipboard environments where uptime and safety are paramount.
Ideal For
Commercial cargo vessels, tankers, bulk carriers, container ships, offshore supply vessels (OSVs), cruise ships, ferries, naval vessels, floating production units (FPSOs), and any marine or offshore installation utilising ABB contactor-based motor control systems.
Technical Support & Compliance
We provide complete solutions including remote troubleshooting, onboard technical support, testing and commissioning, repair services, retrofit and upgrade assistance, and full integration support for ABB timer blocks and contactor accessories. To confirm compatibility with your specific installation, please share nameplate photographs, part numbers, electrical drawings, system model and version details, vessel name and IMO number, and project scope. All compatibility confirmations are subject to confirmation based on the documentation provided.
