Description
ABB TA200DU THERMAL OVERLOAD RELAY (USED)
ABB
TA200DU
THERMAL OVERLOAD RELAY
TA200 DU
UI = 690V / UE = 690V / UIMP = 6KV
600 VAC
TRIP CLASS 10A
AUX.: 18-14 AWG / 12 LB-IN.
FUSES GC NC : 10A / NO : 6A
EN/IEC 60947-4-1/-5-1
GB 14048.4/.5
REF.NO: FKM14677
The ABB TA200DU is a heavy-duty thermal overload relay designed for high-current motor protection in demanding industrial and marine environments. Rated for insulation voltage of 690V and impulse withstand voltage of 6kV, this relay provides reliable overcurrent and thermal protection for electric motors driving essential shipboard systems. Its Trip Class 10A ensures rapid disconnection under fault conditions, safeguarding motors, cabling, and downstream equipment from thermal damage.
Key Features
✓ High insulation voltage rating (UI = 690V) suitable for marine switchboard applications
✓ Trip Class 10A for fast, reliable motor protection under overload conditions
✓ Impulse withstand voltage of 6kV (UIMP) for enhanced electrical safety
✓ Compliant with EN/IEC 60947-4-1/-5-1 international standards
✓ Integrated auxiliary contacts with fuse protection (NC: 10A / NO: 6A) for control circuit integration
Marine Applications
Motor protection in main engine auxiliary systems such as cooling water pumps and lubricating oil pumps
Thermal overload protection for HVAC fan motors and compressor drives onboard vessels
Protection of cargo handling and deck machinery motor circuits
Switchboard motor control centres (MCC) in engine rooms and pump rooms
Integration into fire pump, bilge pump, and ballast system motor starter assemblies
Why Marine Engineers Choose
The ABB TA200DU thermal overload relay is a proven, robust component trusted across commercial and naval fleets worldwide. Its high voltage ratings, compliance with IEC standards, and dependable Trip Class 10A response make it a preferred choice for critical motor protection in harsh marine environments where reliability is non-negotiable.
Ideal For
Bulk carriers, container vessels, tankers, offshore supply vessels (OSVs), cruise ships, naval vessels, FPSOs, ferries, and other commercial or industrial marine platforms requiring reliable motor protection components.
Technical Support & Compliance
We provide complete support services including remote troubleshooting, onboard technical assistance, testing and commissioning, repair, retrofit and upgrade solutions, and full integration support for ABB motor control equipment. To confirm compatibility with your specific installation, please share nameplate photographs, part numbers, electrical drawings, system model and version details, vessel name and IMO number, and project scope. All technical compatibility is subject to confirmation based on the information provided.
