Description
ABB 3ADT220090R0006 MEASUREMENT PCB CARD 3BSE004940R0001 (NEW WITHOUT BOX)
ABB
TYPE: SDCS-PIN-51 / SDCS-PIN-51 COAT
MEASUREMENT PCB CARD
3ADT220090R0006
3BSE004940R0001
REV: G
TYPE: SDSC-REB-1C
PCB CARD
22009009
REV: B
REF.NO: FKM2343
The ABB SDCS-PIN-51 Measurement PCB Card (part numbers 3ADT220090R0006 and 3BSE004940R0001) is a precision signal measurement board designed for use within ABB’s DCS series DC drive systems. Installed in the drive control electronics stack, this card handles analogue measurement functions — current, voltage, and feedback signal acquisition — that are essential for accurate, stable drive operation. Onboard, these drives are widely used in propulsion, deck machinery, bow thrusters, winches, and auxiliary systems where precise DC motor control is required. Correct measurement card function is critical to drive availability and overall vessel operational reliability.
Key Features
✓ Dual type designation: Covers SDCS-PIN-51 and SDCS-PIN-51 COAT variants, with an associated SDSC-REB-1C sub-board, providing measurement and interface functions within the ABB DCS drive platform.
✓ ABB OEM part numbers: Identified by both 3ADT220090R0006 and cross-reference 3BSE004940R0001, ensuring traceability and straightforward verification against ABB documentation.
✓ Analogue measurement functionality: Handles signal acquisition and conditioning for drive feedback loops — typical for current and voltage measurement in DC drive control architectures.
✓ Revision-controlled manufacture: REV G (SDCS-PIN-51) and REV B (SDSC-REB-1C) designations support accurate spares management and like-for-like replacement.
✓ Direct drop-in replacement: Designed for straightforward substitution within compatible ABB DCS drive cabinets, minimising downtime during corrective or planned maintenance.
Marine Applications
DC propulsion drive systems requiring measurement PCB replacement or upgrade within ABB DCS-series drive cabinets.
Deck machinery control — winches, capstans, cranes, and mooring equipment fitted with ABB DC drives where measurement card failure affects load control.
Bow thruster and stern thruster drive systems where accurate current and feedback measurement is critical to manoeuvring performance.
Auxiliary machinery drives including pumps, compressors, and HVAC fan systems controlled via ABB DCS drive platforms.
Planned maintenance and class survey preparation — replacing ageing measurement cards to restore drive performance and avoid unplanned failures at sea.
Why Marine Engineers Choose
ABB DCS series drive components are a common fitment across cargo vessels, tankers, offshore units, and cruise ships. Sourcing the correct OEM measurement PCB — identified by both ABB part numbers — ensures compatibility with existing drive firmware, calibration, and protection settings, avoiding the risks associated with non-original substitutes in safety-critical propulsion and machinery circuits.
Ideal For
Bulk carriers, tankers, container vessels, offshore supply vessels, platform supply vessels, ferry and RoRo operators, dredgers, cable layers, and any vessel fitted with ABB DCS-series DC drive systems in propulsion or machinery control applications.
Technical Support & Compliance
Full technical support is available including remote troubleshooting, onboard installation and commissioning assistance, testing and verification, component-level repair assessment, retrofit and upgrade guidance, and drive system integration support — all subject to confirmation based on your specific installation. To confirm compatibility and ensure the correct part is supplied, please share: nameplate photographs of the existing drive cabinet and PCB card, all visible part numbers and revision markings, the drive system model and software version, vessel name and IMO number where applicable, and the full scope of work or fault description. Compatibility and suitability are subject to confirmation upon review of the above information.
