ABB METRAWATT GTU0100S1F2U01A04K02T2H2 TRANSDUCER (USED)
ABB METRAWATT GMBH
GTU0100S1F2U01A04K02T2H2
TRANSDUCER
2 5 X2=AC 100V
X1= 0
13+ 14- Y2=DC 20MA
Y1= 0.2*Y2
20 21 H=AC88…132V
I0.5*CI TN=0.3S
MADE IN W.-GERMANY
REF.NO: FKM12893
The ABB Metrawatt GTU0100S1F2U01A04K02T2H2 is an AC voltage transducer designed to convert AC voltage input signals into a proportional DC current output. These transducers are critical components in marine power management and electrical monitoring systems, providing accurate measurement data to automation and control systems onboard vessels. Reliable signal conversion ensures proper load management, generator synchronisation monitoring, and electrical distribution oversight — all essential for safe and efficient ship operations.
Key Features
✓ AC voltage input (X2 = AC 100V) with proportional DC current output (Y2 = DC 20mA)
✓ Auxiliary supply voltage range of AC 88–132V, suitable for standard marine power configurations
✓ Fast response time (TN = 0.3s) for real-time electrical monitoring applications
✓ Manufactured by ABB Metrawatt GmbH — a trusted name in precision measurement and industrial instrumentation
✓ Compact transducer design for integration into existing switchboard and control panel arrangements
Marine Applications
Main and emergency switchboard voltage monitoring systems
Generator control and power management system (PMS) signal conditioning
Engine room automation and alarm systems requiring analogue voltage inputs
Shore power connection monitoring and load transfer panels
Electrical distribution and energy management instrumentation onboard
Why Marine Engineers Choose ABB Metrawatt Transducers
ABB Metrawatt transducers are recognised across the maritime industry for their measurement accuracy, proven durability, and seamless integration with vessel automation platforms. The GTU series provides dependable AC-to-DC signal conversion that marine engineers rely on for continuous monitoring of critical electrical parameters in demanding shipboard environments.
Ideal For
Merchant vessels, bulk carriers, tankers, container ships, offshore support vessels (OSVs), cruise ships, naval vessels, and any marine installation utilising ABB or third-party power management and monitoring systems.
Technical Support & Compliance
We provide complete support solutions including remote troubleshooting, onboard technical assistance, testing and commissioning, repair services, retrofit and upgrade guidance, and integration support for existing automation systems. To confirm compatibility with your specific installation, please share nameplate photographs, part numbers, relevant drawings, system model and version details, vessel name and IMO number, and scope of work. All technical compatibility is subject to confirmation based on the information provided.
