Description
ABB COMMANDER SR100 STRIP-CHART RECORDER SR102A/B0/R00000/111STD (USED)
ABB LTD.
COMMANDER SR100
STRIP-CHART RECORDER
TYPE: SR102A/B0/R00000/111STD
AIR-3.69/PIR-6.32
SUPPLY VOLTAGE: ~85-265V A.C
50/60HZ, 30VA MAX.
MADE IN ENGLAND
REF.NO: FKM15377
The ABB Commander SR100 is a strip-chart recorder designed for continuous process variable monitoring and data logging in industrial and marine automation environments. Part number SR102A/B0/R00000/111STD, this unit accepts a wide-range AC supply (85–265V, 50/60Hz) and is manufactured by ABB Ltd. in England. Strip-chart recorders of this type are commonly installed in engine control rooms and automation panels aboard vessels, providing a permanent paper trend record of critical process parameters — essential for watchkeeping, fault diagnosis, and class survey documentation.
Key Features
✓ Wide-range AC supply: Operates on 85–265V AC, 50/60Hz — compatible with most shipboard and industrial power systems without additional step-down transformers.
✓ Continuous strip-chart recording: Delivers a real-time, permanent paper trace of process variables for trend analysis, audit trails, and operational record-keeping.
✓ ABB Commander SR100 platform: Part of ABB’s established Commander series, recognised for reliability in demanding industrial and marine automation environments.
✓ Panel-mount form factor: Suited for integration into existing control panels and automation cabinets typical of marine engine rooms and cargo control stations.
✓ ABB Ltd. manufacture, England: Built to ABB’s industrial quality standards; exact input types, chart speed, and range configuration are subject to confirmation from nameplate data and documentation.
Marine Applications
Engine room process monitoring — continuous recording of temperature, pressure, or other analog signals from main engines and auxiliary machinery systems.
Bridge and cargo control rooms — trending critical parameters for watchkeeping officers and supporting port state control and flag state inspections.
Automation and alarm panels — integration with existing shipboard standalone monitoring loops where a permanent paper record supplements digital logging.
Boiler and steam system surveillance — strip-chart trend recording of steam pressure and feedwater parameters aboard tankers, bulk carriers, and passenger vessels.
Offshore platforms and FPSOs — process parameter logging in control rooms where hard-copy records are required for safety management and regulatory compliance.
Why Marine Engineers Choose
The ABB Commander SR100 offers a proven, no-frills recording solution with broad supply voltage compatibility and a long-established platform, making it a practical choice for maintaining continuity in existing automation systems without requiring full panel replacements or reengineering.
Ideal For
Cargo vessels, tankers, bulk carriers, container ships, offshore platforms, FPSOs, naval auxiliaries, and shore-based industrial facilities requiring continuous process data recording and trend analysis within existing ABB Commander-equipped control and automation systems.
Technical Support & Compliance
Our team provides complete solutions including remote troubleshooting, onboard technical support, testing and commissioning, repair, retrofit and upgrade, and integration support for ABB Commander SR100 strip-chart recorders and associated automation equipment. To confirm compatibility with your installation, please share nameplate photos, full part numbers, available wiring diagrams or drawings, system model and software version, vessel name and IMO number, and the full scope of work required — all compatibility and suitability assessments are subject to confirmation upon review.
