Description
ABB BC6-30-10 MINI CONTACTORS 12A 300VAC (NEW WITHOUT BOX)
ABB
BC6-30-10
MINI CONTACTORS
3 PHASE
3 POLES BREAKING
POWER SUPPLY: 12 A 300 VAC
UE: 220-690VAC
AC-1: 6-20 A
AC-3: 2,2 3,4 KW
IEC/EN 60947-4-1
USE 75°C STANDARD CU WIRE ONLY
10-22 AWG
TORQUE: 7 LB-IN
MADE IN GERMANY
REF.NO: FKM5779
The ABB BC6-30-10 is a compact 3-phase mini contactor rated at 12A and 300VAC, designed for reliable motor switching and electrical load control in space-constrained panel installations. With an operational voltage range of 220–690VAC and compliance with IEC/EN 60947-4-1, it is well suited to marine electrical control boards, machinery automation systems, and auxiliary equipment circuits found throughout the engine room and deck spaces onboard commercial and industrial vessels.
Key Features
✓ 3-phase, 3-pole breaking configuration rated 12A / 300VAC with operational voltage up to 690VAC
✓ AC-1 current range 6–20A and AC-3 motor duty rating 2.2–3.4 kW for versatile load switching
✓ Compliant with IEC/EN 60947-4-1 international standard for low-voltage switchgear and controlgear
✓ Compact mini contactor form factor suited to high-density marine panel assemblies
✓ Manufactured in Germany to ABB quality standards; accepts 10–22 AWG copper wire with a terminal torque of 7 lb-in
Marine Applications
Motor starter and switching circuits in engine room control and automation panels
Pump control for ballast, bilge, and cooling water systems
HVAC and ventilation fan motor switching in accommodation and machinery spaces
Deck machinery and winch auxiliary control circuits
Relay logic and automation panels for safety and monitoring systems onboard
Why Marine Engineers Choose
ABB mini contactors in the BC6 series are a proven choice for marine and industrial panel builders who require a compact, standards-compliant switching device without compromising on current capacity or build quality. German manufacture and IEC/EN 60947-4-1 certification make these suitable for class-reviewed installations where documentation and traceability are required.
Ideal For
Commercial cargo vessels, offshore supply vessels, tankers, bulk carriers, passenger ferries, naval auxiliaries, and industrial marine facilities requiring compact 3-phase contactor solutions for motor and electrical load switching.
Technical Support & Compliance
Our team provides complete solutions including remote troubleshooting, onboard technical support, testing and commissioning, repair, retrofit and upgrade services, and integration support for ABB contactor-based control systems. To confirm compatibility with your installation, please share nameplate photos, existing part numbers, electrical drawings, system model and version, and vessel name or IMO number. All compatibility is subject to confirmation based on the details provided.
