Description
ABB AX32-30-10 CONTACTOR WITH CAL5X-11 AUXILLARY CONTACT BLOCK (USED)
ABB
AX32-30-10
CONTACTOR
UI=690~
ITH=65A LE AC-1=55A
GENERAL USE: 600VAC 50A
AWG 4-8 CU 75°C
CAL5X-11 – (2)
AUXILIARY CONTACT BLOCK
UI=690V~ ITH=16A
600VAC MAX.
50/60HZ
MADE IN CHINA
REF.NO: FKM3206
The ABB AX32-30-10 is a heavy-duty AC contactor designed for controlling motors, lighting circuits, and general electrical loads in demanding industrial and marine environments. Supplied here as a combined assembly with two CAL5X-11 auxiliary contact blocks (1NO+1NC each), this unit is suited for integration into marine switchboards, motor control centres (MCCs), and automation panels where reliable switching and auxiliary signal feedback are essential. At rated voltages up to 690V AC and thermal current ratings appropriate for shipboard distribution systems, the AX32-30-10 is a proven component in vessel electrical infrastructure.
Key Features
✓ ABB AX32-30-10 contactor rated UI=690V~, ITH=65A, AC-1=55A for robust general-purpose switching
✓ Two CAL5X-11 auxiliary contact blocks included (1NO+1NC configuration), enabling local and remote status signalling
✓ Wide voltage compatibility — rated for general use at 600VAC 50A, suitable for standard shipboard distribution voltages
✓ 50/60 Hz operation — compatible with both frequency standards used across international fleets
✓ Compact, modular design — auxiliary blocks mount directly to the contactor body, simplifying panel layout and wiring
Marine Applications
Motor control centres (MCCs) and main switchboard feeder panels
Pump motor starters — ballast, bilge, fire, and general service pumps
HVAC and ventilation fan motor control circuits
Deck machinery and auxiliary equipment control panels
Automation and PLC interface circuits requiring auxiliary contact feedback signals
Why Marine Engineers Choose ABB Contactors
ABB AX-series contactors are widely specified across commercial and offshore vessels for their consistent switching performance, straightforward installation, and broad availability of compatible accessories. The modular auxiliary contact system allows panel builders and engineers to configure status monitoring and interlock circuits without additional external relays, reducing wiring complexity and panel footprint in space-constrained spaces.
Ideal For
Merchant vessels, offshore support vessels, platform supply vessels (PSVs), tugs, dredgers, fishing vessels, and industrial marine installations requiring proven IEC-rated switchgear components for motor and load control applications.
Technical Support & Compliance
Our team provides complete solutions including remote troubleshooting, onboard technical support, testing and commissioning assistance, component repair, retrofit and upgrade services, and full integration support for switchboard and MCC installations. Compatibility with your existing panel or control system is subject to confirmation — please share nameplate photographs, full part numbers, wiring diagrams or drawings, system model and software version where applicable, and vessel name or IMO number so we can confirm the correct fit before supply.
