Description
ABB AF16-40-00-11 4-POLE CONTACTOR (USED)
ABB
AF16-40-00-11
4-POLE CONTACTOR
24-60V 50/60HZ
20-60VDC
Ui = 690V ~
Uimp = 6KV
LTH = 35A
LEAC – 1= 30A
GENERAL USE: 600VAC 30A
AWG 10-16 CU 75°C
TORQUE: 13 LB.IN -1,5 NM
COIL: AWG 14-18 CU 75°C
TORQUE: 11LB.IN -1,2 NM
MADE IN FRANCE
REF.NO: FKM10605
The ABB AF16-40-00-11 is a 4-pole contactor engineered for reliable electrical switching and motor control in demanding marine and industrial installations. Its wide-range coil input — 24–60V AC (50/60Hz) and 20–60V DC — allows operation across varied onboard power supply conditions without requiring separate coil variants. With an insulation voltage of 690V and impulse withstand of 6kV, this unit is well suited to marine switchboards, motor control centres, distribution panels, and automation systems aboard commercial and offshore vessels.
Key Features
✓ 4-pole configuration for switching three-phase loads with neutral, suitable for balanced and asymmetrical distribution circuits
✓ Wide-range coil input: 24–60V AC (50/60Hz) and 20–60V DC, reducing the need for multiple coil variants across mixed-voltage fleets
✓ Insulation voltage Ui = 690V and impulse withstand Uimp = 6kV, meeting the protection demands of marine-grade electrical panels
✓ Thermal current rating LTH = 35A; AC-1 rated at 30A for general-purpose resistive and low-inductive load applications
✓ Manufactured in France to ABB quality standards; DIN rail mountable for straightforward integration into existing panel assemblies
Marine Applications
Motor control centres and direct-on-line starter panels aboard cargo vessels, tankers, and bulk carriers
Main switchboard feeder and distribution circuit switching on offshore platforms and OSVs
HVAC compressor and fan motor control in machinery spaces and accommodation areas
Engine room automation and auxiliary control panel switching applications
General electrical distribution and load management aboard ferries, workboats, and naval support vessels
Why Marine Engineers Choose ABB AF16-40-00-11
ABB contactors are a trusted standard in marine electrical installations worldwide, valued for robust construction, wide operating range, and consistent performance under the thermal and vibration conditions typical onboard. The AF16 series wide-range coil simplifies spares inventory and reduces the risk of mismatched installation across vessels operating on different supply voltages.
Ideal For
Cargo vessels, tankers, bulk carriers, offshore support vessels, ferries, workboats, naval vessels, dredgers, and industrial marine platforms requiring dependable 4-pole contactor solutions for switchboard, motor control, and distribution panel applications.
Technical Support & Compliance
Our team provides complete solutions including remote troubleshooting, onboard technical assistance, testing and commissioning, repair and overhaul, retrofit and upgrade services, and full integration support for ABB contactor installations. To confirm compatibility with your specific installation, please share nameplate photographs, part numbers, engineering drawings, system model and version details, vessel name, IMO number, and the scope of work. Compatibility and suitability are subject to confirmation based on the information provided.
