Description
ABB AF09-30-10-11 CONTACTOR (NEW OPEN BOX)
ABB
AF09-30-10-11
CONTACTOR
1SBL137001R1110
POWER SUPPLY: 24-60V 50/60HZ, 20-60VDC
UI = 690V~ LTH = 35A
UIMP = 6KV LEAC-1 = 25A
GENERAL USE: 600VAC 25A
AWG 10-16 CU 75°C
TORQUE 13LB.IN – 1,5NM
A600 Q600
MADE IN FRANCE
REF.NO: FKM10528
The ABB AF09-30-10-11 is a compact 3-pole contactor from ABB’s AF series, designed for reliable switching and control of electrical loads in demanding industrial and marine environments. Its wide-range coil accepts both AC (24–60V, 50/60Hz) and DC (20–60V) supply voltages, providing flexibility across vessel electrical systems. Rated at 690V~ with a general-use rating of 600VAC/25A, it is well suited for motor starters, auxiliary power distribution panels, pump control circuits, and machinery control onboard commercial and offshore vessels.
Key Features
✓ Wide-range coil: 24–60V AC (50/60Hz) and 20–60V DC, simplifying integration across mixed shipboard supply voltages
✓ Rated insulation voltage UI = 690V~; impulse withstand voltage UIMP = 6kV for demanding marine electrical environments
✓ General-use rating 600VAC/25A; LEAC-1 = 25A; thermal current LTH = 35A
✓ Compatible with AWG 10–16 copper conductors (75°C rated); terminal torque 1.5Nm (13 lb.in) for secure, reliable connections
✓ Manufactured in France to ABB quality standards; catalog reference 1SBL137001R1110
Marine Applications
Motor starter and control circuits for deck machinery, pumps, and ventilation fans
Auxiliary power distribution panels and switchboard feeder control
HVAC, ventilation, and cooling system motor switching aboard commercial vessels
Bilge pump, ballast pump, and fire pump circuit control
Engine room automation panels and machinery control systems
Why Marine Engineers Choose
The ABB AF series is a proven choice in marine electrical installations for its compact footprint and broad coil voltage tolerance. The AF09-30-10-11’s dual AC/DC coil capability reduces the need for multiple contactor variants across mixed-voltage vessel systems, simplifying spares inventory management and onboard maintenance routines.
Ideal For
Cargo vessels, bulk carriers, offshore support vessels, platform supply vessels, tankers, ferries, fishing vessels, and industrial marine applications requiring compact, dependable motor and load switching control.
Technical Support & Compliance
Our technical team provides complete solutions including remote troubleshooting, onboard support, testing and commissioning, repair, retrofit and upgrade assistance, and system integration support. Compatibility with your specific installation is subject to confirmation — please share nameplate photos, part numbers, engineering drawings, system model and version, vessel name, IMO number, and full scope of supply to allow us to confirm suitability and availability.
