Description
ABB ACS150-03E-05A6-4 INVERTER MICRO DRIVE (NEW OPEN BOX)
ABB
INVERTER MICRO DRIVE
P/N: ACS150-03E-05A6-4
68581796
AC MOTOR SPEED CONTROLLER
IP20/UL OPEN TYPE
2.2 KW
U1: 3~380â¦.480 V
I1: 9.6 A
F1: 48â¦63 HZ
U2: 3~0â¦U1V
I2: 5.6 A
F2: 0â¦500 HZ
THE ACS150-03E-05A6-4 FROM ABB IS A 380VAC TO 480VAC THREE PHASE AC SUPPLY ABB MICRO DRIVE ACS150 IS DESIGNED TO BE INCORPORATED INTO A WIDE VARIETY OF MACHINES SUCH AS MIXERS, CONVEYORS, FANS OR PUMPS OR ANYWHERE WHERE A FIXED SPEED MOTOR NEEDS TO GO VARIABLE SPEED MOTOR. THE ACS150 DRIVES HAVE AN INTEGRATED USER PANEL AND POTENTIOMETER AND A VARIETY OF FEATURES SUCH AS MACROS WHICH ARE PRE-DEFINED I/O CONFIGURATIONS LIKE 3-WIRE, PID-CONTROL AND MOTOR POTENTIOMETER MACRO. IN ADDITION, THE DRIVES OFFER EXTENSIVE RANGE OF PARAMETERS THAT HELP OBTAINING THE BEST PERFORMANCE OUT OF THE APPLICATION. FLASHDROP, AN OPTIONAL DRIVE CONFIGURATION TOOL DESIGNED FOR VOLUME CONFIGURATION, CAN BE USED TO QUICKLY AND EASILY CONFIGURE UNPOWERED DRIVES. FLASHDROP STORES UP TO 20 DIFFERENT DRIVE PARAMETER SETS AND CAN COPY PARAMETERS FROM ONE DRIVE TO ANOTHER, OR BETWEEN A PC AND A DRIVE.
REF: FKM4537V1
The ABB ACS150-03E-05A6-4 is a compact 2.2 kW micro drive AC motor speed controller rated for three-phase 380–480V supply at 48–63 Hz. Designed to convert fixed-speed AC motors to variable speed operation, it is well-suited for marine auxiliary machinery including pumps, fans, blowers, conveyors, and mixers across engine room, cargo, and deck systems. Precise motor speed regulation supports fuel efficiency, controlled process flow, and reduced mechanical wear in demanding shipboard environments.
Key Features
✓ 2.2 kW output capacity with three-phase 380–480V input and wide supply frequency tolerance (48–63 Hz) for compatibility with vessel power systems
✓ Variable output frequency (0–500 Hz) enabling precise speed control across a broad range of AC induction motor applications
✓ Integrated user panel and potentiometer for local speed reference setting without additional external control hardware
✓ Pre-defined I/O macros including 3-wire, PID control, and motor potentiometer configurations for fast, consistent commissioning
✓ FlashDrop compatibility for storing and transferring up to 20 parameter sets, simplifying volume configuration and drive-to-drive parameter copying
Marine Applications
Variable speed control of seawater cooling pumps, freshwater pumps, and bilge pumps in engine room systems
Fan and blower speed regulation for engine room ventilation and HVAC auxiliary systems
Conveyor and auxiliary deck machinery drive control in cargo handling operations
Mixer and agitator drives in ballast treatment, chemical dosing, and cargo hold systems
General variable speed motor control across accommodation, galley, and vessel utility systems
Why Marine Engineers Choose ABB ACS150
The ABB ACS150 micro drive is a compact, proven variable speed drive solution widely used in marine auxiliary applications where reliable speed control, straightforward commissioning, and a globally supported brand are priorities. Its integrated panel, macro-based I/O configuration, and extensive parameter set reduce installation time and allow onboard tuning without specialist tooling.
Ideal For
Merchant vessels, offshore platforms, naval auxiliaries, passenger ships, fishing vessels, and industrial marine installations requiring a compact variable speed drive for pumps, fans, blowers, conveyors, and general auxiliary motor applications.
Technical Support & Compliance
We provide complete solutions including remote troubleshooting, onboard technical support, testing and commissioning, repair, retrofit and upgrade services, and integration support for ABB drive installations. Compatibility with your existing motor, switchboard, and control system is subject to confirmation. To verify suitability, please share nameplate photos, part numbers, wiring drawings, system model and version, vessel name and IMO number, and the full scope of your application.
